Meet all applications, such as tool, motor cylinder, hydro-cylinder, air cylinder and actuator electric stoke measurement function requirement. Achieve 0.1mm accuracy technology request and high precision motion control.

Small size, compact body and reduce installation space
Sealing to IP66 and corrosion and suitable for hostile environments
Cable integrally moulded and excellent strain relief with secure sealing
Meet EMC 2004/108/EC
TEMP for working -30 to 100℃
Kids of installation ways

Electric stroke from 10-1600mm viable
Supply Voltage 10-30Vdc
Electric output signal 0-5Vdc, 0.5-4.5Vdc, 0-10Vdc and 4-20mA viable
Electric life cycles meet more than 10 million
Hybrid track comprises a high resistivity conductive plastic film bonded to aprecision wire-wound element, signal module can choose.
